Screening of Carbon Dioxide Injury Characteristic Components in Fresh-cut Broccoli

doi:10.11923/j.issn.2095-4050.cjas2024-0103

Abstract

Abstract:

This study aims to identify the characteristic components of carbon dioxide injury in fresh-cut broccoli and establish a foundation for early warning and precise control of CO₂ concentration, thereby enhancing the effectiveness of air conditioning and preservation. Gas chromatography-mass spectrometry was employed to analyze the trend of volatile components produced by broccoli under dynamic controlled atmosphere storage. The results indicated that fresh-cut broccoli sustained injury when stored at 0°C with 4% O₂ and 3% or higher CO₂ concentration, with the injury phenotype being off-odor. The contents of propionic acid specifically increased under injured conditions, displaying a significantly different trend compared to hypoxic conditions. Thus, propionic acid can be used as a characteristic component of carbon dioxide injury in fresh-cut broccoli.

Key words: fresh-cut, broccoli, carbon dioxide injury, characteristic components, propionic acid

ZHU Chunrong, WANG Qingguo. Screening of Carbon Dioxide Injury Characteristic Components in Fresh-cut Broccoli[J]. Journal of Agriculture, 2025, 15(8): 77-87.

Figures/Tables 11

References 31

[1]	张慜, 马良. 对我国鲜切果蔬微加工行业及安全性的思考[J]. 江南大学学报(人文社会科学版), 2016, 15(5):110-114.
[2]	韩晨瑞, 申靖, 刘航, 等. 鲜切果蔬物理保鲜技术研究进展[J]. 食品科技, 2022, 47(11):17-23.
[3]	梁辉, 赵安娜, 涂贻轩, 等. 西兰花采后霉变控制技术研究[J]. 中国果菜, 2024, 44(2):3-6+34.
[4]	赵伊诺, 金鑫, 毕金峰, 等. 不同烫漂方式及冷冻速率对预制西兰花质构品质影响[J]. 食品科学, 2024, 45:1-16.
[5]	张玉萍, 莫丽媛, 丁惠敏, 等. 双乙酰处理对鲜切西兰花贮藏品质及抗氧化能力的影响[J]. 食品与发酵工业, 2024, 55:1-15.
[6]	GAO J, ZHU Y Q, LUO F Y. Effects of ethanol combined with ascorbic acid and packaging on the inhibition of browning and microbial growth in fresh-cut Chinese yam[J]. Food science and nutrition, 2018, 6(4):998-1005.
[7]	LI X T, MENG Z, MALIK A U, et al. Maintaining the quality of postharvest broccoli by inhibiting ethylene accumulation using diacetyl[J]. Frontiers in nutrition, 2022, 9:1055651.
[8]	李宇晴, 卢立新, 王清. 二氧化氯熏蒸处理对西兰花品质的影响[J]. 食品与机械, 2024, 40(3):120-126+172.
[9]	陈学玲, 张莉会, 何建军, 等. 杀菌剂对鲜切西兰花的保鲜作用[J]. 现代食品科技, 2018, 34(6):197-203.
[10]	丁娇, 汤静, 董小盼, 等. 超声处理对鲜切西兰花的保鲜效果[J]. 食品科学, 2024, 45(10):224-231.
[11]	梁端宾, 刘峻. 活性PE保鲜膜对鲜切西兰花的保鲜性能研究[J]. 绿色包装, 2023(12):15-21.
[12]	张翠翠, 马亚丹, 李林杰, 等. 可溶性糖介导的荧光照射延缓鲜切西兰花衰老黄化[J]. 食品科学, 2019, 40(9):207-212. doi: 10.7506/spkx1002-6630-20180504-041
[13]	ZHANG Y, CHEN Y, GUO Y, et al. Elevated CO₂ delayed yellowing by maintaining chlorophyll biosynthesis and inhibiting chlorophyll degradation and carotenoid accumulation of postharvest broccoli[J]. Postharvest biology and technology, 2022, 194:112089.
[14]	GAJEWSKI M, PRZYBYL J L, BAJER M, et al. The influence of controlled atmosphere storage on phytosterols in broccoli heads[J]. Journal of food processing and preservation, 2011, 35(5):722-728.
[15]	SCHOUTEN R E, ZHANG X, VERSCHOOR J A, et al. Development of colour of broccoli heads as affected by controlled atmosphere storage and temperature[J]. Postharvest biology and technology, 2009, 51(1):27-35.
[16]	吕凤艳, 郭衍银, 王兆全. 西兰花气调保鲜过程中O₂缓解CO₂伤害的研究[J]. 北方园艺, 2016(13):132-136.
[17]	张鹏, 陈曦冉, 贾晓昱, 等. CO₂伤害对软枣猕猴桃风味品质的影响[J]. 食品工业科技, 2023, 44(4):378-386.
[18]	HO P L, TRAN D T, HERTOG M L A T M, et al. Effect of controlled atmosphere storage on the quality attributes and volatile organic compounds profile of dragon fruit (Hylocereus undatus)[J]. Postharvest biology and technology, 2021, 173:111406.
[19]	LIAO Y, ZENG L, TAN H, et al. Biochemical pathway of benzyl nitrile derived from l-phenylalanine in tea (Camellia sinensis) and its formation in response to postharvest stresses[J]. Journal of agricultural and food chemistry, 2020, 68(5):1397-1404.
[20]	CEFOLA M, AMODIO M L, CORNACCHIA R, et al. Effect of atmosphere composition on the quality of ready-to-use broccoli raab (Brassica rapa L.)[J]. Journal of the science of food and agriculture, 2010, 90(5):789-797.
[21]	WANG L, ZHANG Y, CHEN Y, et al. Investigating the relationship between volatile components and differentially expressed proteins in broccoli heads during storage in high CO₂ atmospheres[J]. Postharvest biology and technology, 2019, 153:43-51.
[22]	LING S Q, QIU H L, XU J ZH, et al. Volatile dimethyl disulfide from guava plants regulate developmental performance of asian citrus psyllid through activation of defense responses in neighboring orange plants[J]. International journal of molecular sciences, 2022, 23(18):10271-10271.
[23]	HE Q, XIAO K. Quality of broccoli (Brassica oleracea L. var. italica) in modified atmosphere packaging made by gas barrier-gas promoter blending materials[J]. Postharvest biology and technology, 2018, 144:63-69.
[24]	SALAS N A, MOLINA-CORRAL F J, GONZÁLEZ-AGUILAR G A, et al. Volatile production by ‘Golden Delicious’ apples is affected by preharvest application of aminoethoxyvinylglycine[J]. Scientia horticulturae, 2011, 130(2):436-444.
[25]	CONTRERAS C, ALSMAIRAT N, BEAUDRY R, et al. Prestorage conditioning and diphenylamine improve resistance to controlled-atmosphere-related injury in ‘Honeycrisp’ apples[J]. HortScience, 2014, 49(1):76-81.
[26]	CANTWELL M and T SUSLOW. Broccoli: recommendations for maintaining postharvest quality[EB/OL]. 2024-11-18. https://postharvest.ucdavis.edu/produce-facts-sheets/broccoli.
[27]	ESCALONA V H, AGUAYO E ARTES F, et al. Metabolic activity and quality changes of whole and fresh-cut kohlrabi (Brassica oleracea L. gongylodes group) stored under controlled atmospheres[J]. Postharvest biology and technology, 2006, 41(2):181-190.
[28]	CAO Y, ZHU S, ZHANG L, et al. Qualitative and quantitative determination of trace aldehydes and ketones in food preservative propionic acid for quality improvement[J]. Analytical methods, 2021, 13(26):2989-2996.
[29]	张佳伟, 贾玉山, 格根图, 等. 不同丙酸浓度对天然牧草青贮品质及有氧稳定性的影响[J]. 草地学报, 2022, 30(9):2522-2528. doi: 10.11733/j.issn.1007-0435.2022.09.035
[30]	邹沫君. RP-HPLC法测定面包中丙酸[J]. 食品工业, 2020, 41(1):288-290.
[31]	XU Q, FU H, ZHU B, et al. Potassium improves drought stress tolerance in plants by affecting root morphology, root exudates, and microbial diversity[J]. Metabolites, 2021, 11(3):131.

序号	物质名称	保留时间/min	序号	物质名称	保留时间/min
1	乙醇	3.83	11	二甘醇	28.625
2	甲苯	6.612	12	四乙二醇二乙醚	29.284
3	二甲基二硫醚	7.044	13	二甘醇单乙醚	29.291
4	十二烷	7.439	14	3,6,9,12-四氧十四烷-1-醇	29.293
5	对二甲苯	8.542	15	12-冠醚-4	30.735
6	右旋柠檬烯	10.181	16	四乙二醇	33.31
7	苯乙烯	11.995	17	正十六烷酸	34.782
8	丙酸	20.194	18	十八烷酸	36.954
9	己酸己酯	21.46	19	五乙二醇	38.766
10	α-法呢烯	24.666	-	-	-

序号	物质名称	保留时间/min	序号	物质名称	保留时间/min
1	乙醇	3.83	11	二甘醇	28.625
2	甲苯	6.612	12	四乙二醇二乙醚	29.284
3	二甲基二硫醚	7.044	13	二甘醇单乙醚	29.291
4	十二烷	7.439	14	3,6,9,12-四氧十四烷-1-醇	29.293
5	对二甲苯	8.542	15	12-冠醚-4	30.735
6	右旋柠檬烯	10.181	16	四乙二醇	33.31
7	苯乙烯	11.995	17	正十六烷酸	34.782
8	丙酸	20.194	18	十八烷酸	36.954
9	己酸己酯	21.46	19	五乙二醇	38.766
10	α-法呢烯	24.666	-	-	-

保留时间/min	相对含量/%					物质名称
保留时间/min	1% CO₂	2% CO₂	3% CO₂	4% CO₂	5% CO₂	物质名称
3.83	1.57	1.23	3.10	2.61	2.55	乙醇
6.612	0.58	0.72	1.12	0.81	0.79	甲苯
7.044	0.66	0.66	0.88	1.16	1.36	二甲基二硫醚
7.439	0.66	0.63	0.77	0.67	0.84	十二烷
8.542	2.47	2.60	3.01	2.40	2.25	对二甲苯
10.181	0.64	0.44	0.68	0.88	0.49	右旋柠檬烯
11.995	0.61	0.56	0.91	0.47	0.40	苯乙烯
20.194	0	0.32	0.81	0.86	0.99	丙酸
21.46	0.54	0.42	0.68	0.69	0.37	己酸己酯
24.666	0.52	0.60	0.46	0.91	0.56	α-法呢烯
28.625	1.34	1.16	2.28	1.59	1.94	二甘醇
29.284	19.20	12.99	16.42	9.32	5.56	四乙二醇二乙醚
29.291	0.98	0.95	1.19	2.17	1.55	二甘醇单乙醚
29.293	2.97	4.16	2.39	3.15	1.39	3,6,9,12-四氧杂十四烷-1-醇
30.735	0.54	0.99	3.11	1.69	0.71	12-冠醚-4
33.31	2.38	2.43	2.81	3.12	2.80	四乙二醇
34.782	34.44	16.10	16.04	20.55	38.62	正十六烷酸
36.954	12.02	14.16	12.76	15.61	38.50	十八烷酸
38.766	33.88	13.61	35.41	18.75	15.31	五乙二醇

保留时间/min	相对含量/%					物质名称
保留时间/min	1% CO₂	2% CO₂	3% CO₂	4% CO₂	5% CO₂	物质名称
3.83	1.57	1.23	3.10	2.61	2.55	乙醇
6.612	0.58	0.72	1.12	0.81	0.79	甲苯
7.044	0.66	0.66	0.88	1.16	1.36	二甲基二硫醚
7.439	0.66	0.63	0.77	0.67	0.84	十二烷
8.542	2.47	2.60	3.01	2.40	2.25	对二甲苯
10.181	0.64	0.44	0.68	0.88	0.49	右旋柠檬烯
11.995	0.61	0.56	0.91	0.47	0.40	苯乙烯
20.194	0	0.32	0.81	0.86	0.99	丙酸
21.46	0.54	0.42	0.68	0.69	0.37	己酸己酯
24.666	0.52	0.60	0.46	0.91	0.56	α-法呢烯
28.625	1.34	1.16	2.28	1.59	1.94	二甘醇
29.284	19.20	12.99	16.42	9.32	5.56	四乙二醇二乙醚
29.291	0.98	0.95	1.19	2.17	1.55	二甘醇单乙醚
29.293	2.97	4.16	2.39	3.15	1.39	3,6,9,12-四氧杂十四烷-1-醇
30.735	0.54	0.99	3.11	1.69	0.71	12-冠醚-4
33.31	2.38	2.43	2.81	3.12	2.80	四乙二醇
34.782	34.44	16.10	16.04	20.55	38.62	正十六烷酸
36.954	12.02	14.16	12.76	15.61	38.50	十八烷酸
38.766	33.88	13.61	35.41	18.75	15.31	五乙二醇
